BZJ5538 Bottle packing Semi Automatic Sleeve Wrapper and BS4522 Shrink Tunnel Packager

Item ID:
BZJ5538+BS4522
Stock:
100
Price:
$2,550.00

1 - 10 = $2,550.00

11 - 50 = $2,450.00

51 - 500 = $2,350.00

Sold Out
Specifications
BrandDINGXIN
ModelBZJ5538+BS4522
Power supply220-240V, 50-60Hz;17kw
Capacity2-6pcs/minute
Sealing time/shrink time0.5-1.5s; 0-0.6s
Air source supply170L/min 0.3-0.5Mpa
Max diameter of film rollφ30mm
Film widthMax. 550mm
Film thickness0.03-0.25mm
Max. packing dimension(L*W*H)450 x 270 x 350mm
Min. packing dimension(L*W*H)250 x 60 x 60mm
Machine weight225KGS
Machine size(L*W*H)2020 x 1530 x 3580mm
Shrink filmPE
DescriptionProduct DescriptionVedioPacking & Delivery
Characteristic:
1. Upper and down electromagnetic switch prevent sealing mistakes, and protect operator.
2. Every simply and easy to adjust machine to match different packing size.
3. Simple operation and maintenance with high packing efficiency.
4. Schneider' AC contractor, and Intelligent temperature controller performs stable.
5. Automatic alarm security system protects machine and operator.
6. Large power conveyer motor, with stepless speed regulating, ensures smooth feeding.
7. Two large power fans make the temperature of shrink tunnel every even and stable, this ensures the excellent effect of shrinking in one time.
8. Super cooling system cools the packing and makes the figuration perfectly.

Model
BZJ5538
Model
BS4522
Power supply
220-240V, 50-60Hz;1.8KW
Power supply
3phase 220V/380V 50-60HZ
Capacity
2-6pcs/minute
Heater power
20KW Adjuster
Sealing time/shrink time
0.5-1.5s, 0-0.6s
Conveyer speed
0-10m/minute
Air source supply
170L/min 0.3-0.5Mpa
Tunnel size(L*W*H)
1500*500*460MM
Film width
Max. 550mm
Conveyer loading
30KGS MAX.
Film thickness
0.04-0.12mm
Shrink film
PE,POF,PVC,PP
Max. packing dimension(L*W*H)
450 x 270 x 350mm
Machine weight
470KG
Min. packing dimension(L*W*H)
250 x 60 x 60mm
Machine size
2500*820*1680MM
Machine size(L*W*H)
1020 x 830 x 1980mm
Packing size
1120*940*2000mm

Product  Description
Product  Description
Product  Description
Product  Description
Product  Description
Product  Description
Product  Description
BZJ5538:
Packing & Delivery
Packing & Delivery

BS4522:
Packing & Delivery
Packing & Delivery
